Error in Dabrowa Gor. East station.

[Meda]

The permanently occupied section in the upper left corner of the panel - above the Poz2T button and lies in the track from Dabrowy Gor.





[Schyrsivochter]

You are misunderstanding the meaning of these lamps. This is a type C line block.

The upper track has the line repetition interlock (Pwl) active. It goes active when you have cleared a route onto this track. You then have to press Po to confirm the departure of the train and block the line. At that point, the Po field on your side and the Ko field on the other end will turn red. When the train has arrived on the other end, the dispatcher there will press Ko to unblock, and only then can you send the next train.

The middle field is the ‘permission’ field. It’s red on the lower track because the other end is currently allowed to send trains on that track and you aren’t.

[Meda]

Thank you very much for the explanation.
